Filament Tape

Filament Tape, also called mono-directional filament tape or strapping tape, is a pressure-sensitive tape built from a transparent BOPP or PET film backing embedded with continuous glass yarn (fiberglass) filaments running lengthwise, then coated with a synthetic rubber, hot-melt, or acrylic adhesive. The embedded filaments give the tape exceptional one-way tensile strength (often 150–660 N/25 mm) while keeping it thin, flexible, and hand-tearable across the width — making it the standard solution for heavy bundling, carton reinforcement, and L-clip closure where ordinary packing tape would snap.

Send An Inquiry

Detailed Introduction

Features:

Extreme MD Tensile Strength: Glass yarn reinforcement delivers 150–660 N/25 mm (≈ 85–380 lb/in) tensile strength along the length; resists snapping under heavy load.
Low Elongation: Breaks at 3%–5% stretch — holds tight without creeping, ideal for strapping and unitizing.
Abrasion & Moisture Resistant: BOPP/PET backing shields filaments from scuffing, humidity, and light solvent contact.
Aggressive Adhesion: Synthetic rubber/hot-melt bonds to corrugated, recycled board, plastic, and bare metal; acrylic grade for low-temperature and aging resistance.
Transparent Backing: Lets barcodes, shipping labels, and printed carton graphics stay visible underneath.
Hand-Tearable Across Width: Cuts cleanly perpendicular to filaments with a dispenser or scissors; no fraying along the length.
Tamper-Evident Option: High-strength hold makes unauthorized opening obvious on sealed cartons.

Applications:

Bundling: Pipes, bars, rods, lumber, metal profiles, cable coils, plastic extrusions.
Carton Reinforcement: Strapping heavy corrugated boxes, reinforcing flap seams and edges.
L-Clip Closure: Replacing metal clips on carton tops in automated packaging lines.
Pallet Unitizing: Securing stacked goods, preventing shift during transit.
Appliance & Electronics: Holding doors, shelves, and internal parts of fridges/washers during shipping.
Temporary Fixturing: Holding components in place during assembly or machining.

Specifications:

Characteristics	Standard Value
Adhesive/Easy tear	Hot melt adhesive
Carrier/Backing	PET
Thickness	120mic-180mic(total)
Width	12mm-1060mm
Length	10m- 1000m
Core	Paper core
Print	Transparent
Packing	1)1-6 rolls shrinking 2)36-144 rolls per carton or as customers’ requirment
Certifications	ISO 9001:2000 , REACH,SGS Test
Customizing Service	1)Semi-finished products (Jumbo roll) and finished products(small roll)can be provided 2)OEM service is available

*Availability to produce on request widths and characteristics different from standard.
